Maximum SpeedForward≤25km/h;Reverse≤9km/hDriving Range80-90km (Flat terrain, no load)
Grade Ability30% (≈16.7°)Turning Radius≤3.5m
No.of Passenger 2 Persons Dimension2950×1220×1230mm
Wheelbase2100mm TrackFront: 870mm;Rear: 985mm
Minimum gap150mm     Payload350kg
Cargo box Size1200×1100×300mmCargo box MaterialHigh strength aluminium
Weight510kg(Battery included)Charging time8-10hours(Discharge rate 80%)
MotorGREENMAN,Three-phase asynchronous, AC, 48V/4KW
BatteryMaintenance free battery 8×6V /180AH
ControllerToyota, 48M350,48V/350A
Dashboard Battery Indicator
Wire harnessWaterproof wire harness IP67
Charger48V/25A, automatic power off, overload protection
FrameHigh strength aluminum alloy chassis
SuspensionFront suspension:Macpherson independent suspension, Rear suspension:Single leaf spring and telescopic hydraulic shock absorbers
Real axleComplete rear axle, speed reducing ratio 16:1, Italian technology, Cast aluminum alloy gearbox housing
SteeringBidirectional output gear rack steering machine
BrakesFour-wheel hydraulic drum brake & Electromagnetic excitation brake & Electric parking
TireFront :18×8.5-8(4ply);Rear :225/55-12;
CanopyInjection, form in one piece, rain guide function
BodyModified PP injection cover, automobile grade color registers coating
WindshieldPC shield
SeatPU seat
Seat DirectionSame direction, one row,two seats
LightLED headlight
OthersElectric cylinder,trailer frame, backup buzzer and horn
Color□ Dark Green
Optional AccessoriesPart No.94.7101711Integrated panel kit ( speedometer,mileage ,battery indicator)
Part No. Canopy kit ( canopy ,windshield,wing mirror)
