Maximum SpeedForward≤25km/h;Reverse≤9km/hDriving Range70-90km (Flat terrain, no load)
Grade Ability30% (≈16.7°)Turning Radius≤3.5m
No.of Passenger 2 Persons Dimension3170×1220×1280mm
Wheelbase2100mm TrackFront: 870mm;Rear: 985mm
Minimum gap150mm     Payload700kg
Cargo box Size1455×1200×390mmCargo box MaterialHigh strength carbon steel
Weight640kgCharging time8-10hours(Discharge rate 80%)
MotorGREENMAN,Three-phase asynchronous, AC, 48V/4KW
BatteryMaintenance free battery 8×6V/200AH
ControllerToyota, 48M350,48V/350A
Dashboard Battery Indicator
Wire harnessWaterproof wire harness IP67
Charger48V/25A, automatic power off, overload protection
FrameHigh strength carbon steel chassis
SuspensionFront suspension:Macpherson independent suspension, Rear suspension:Single leaf spring and telescopic hydraulic shock absorbers
Real axleComplete rear axle, speed reducing ratio 16:1, Italian technology, Cast aluminum alloy gearbox housing
SteeringBidirectional output gear rack steering machine
BrakesFour-wheel hydraulic drum brake & Electromagnetic excitation brake & Electric parking
TireFront :18×8.5-8(4ply);Rear :20.5 x8-10
BodyModified PP injection cover, automobile grade color registers coating
SeatPU seat
Seat DirectionSame direction, one row,two seats
LightLED headlight;
OthersElectric cylinder,trailer frame and backup buzzer
ColorDark Green
Optional AccessoriesPart No.94.7101711Integrated panel kit ( speedometer,mileage ,battery indicator)
Part No. Canopy kit ( canopy ,windshield,wing mirror)
