Maximum SpeedForward≤22km/h;Reverse≤9km/hDriving Range50-60km (Flat terrain, no load)
Grade Ability30% (≈16.7°)Turning Radius≤4
No.of Passenger 2 Persons Dimension3460×1245×1850mm
Wheelbase2500mm TrackFront: 870mm;Rear: 985mm
Minimum gap114mm     Payload310kg
Cargo box Size1550×1100×250mmCargo box MaterialBlack high strength carbon steel
Weight530kg(Battery included)Charging time8-10hours(Discharge rate 80%)
MotorKDS(ADC), ZQS-3.8B-T1-EJ1,DC,48V/3.8KW
BatteryTrojan 6×8V/170AH or US 6x8V/170AH
ControllerCurtis 1268-5403,48 V/400A
Dashboard Battery Indicator
Wire harnessWaterproof wire harness IP67
Charger48V/25A, automatic power off, overload protection
FrameHigh strength aluminum alloy chassis
SuspensionFront suspension:Macpherson independent suspension , Rear suspension:Single leaf spring and telescopic hydraulic shock absorbers
Real axleComplete rear axle, speed reducing ratio 16:1, Italian technology, Cast aluminum alloy gearbox housing
SteeringBidirectional output gear rack steering machine
BrakesFour-wheel hydraulic drum brake & Electromagnetic excitation brake & Electric parking
TireCarlisle 18×8.5-8 (6ply), ≤22psi
CanopyInjection, form in one piece, rain guide function
BodyModified PP injection cover, automobile grade color registers coating
WindshieldPC shield
SeatPU seat
Seat DirectionSame direction, 1 row,2 seats
LightLED headlight
OthersElectric cylinder , trailer  frame ,Backup buzzer and horn
Color□ White □ Red □ Green
