Maximum SpeedForward≤22km/h;Reverse≤9km/hDriving Range50-60km (Flat terrain, no load)
Grade Ability40% (≈21.8°)Braking Distance2.5m
Turning Radius≤2.8mDimension2510×1220×1850(mm)
Wheelbase1650mm TrackFront: 870mm;Rear: 985mm
Minimum gap114mm     Payload260kg (2persons)
Weight430kg (Battery included)Charging time8-10hours(Discharge rate 80%)
MotorKDS(ADC), ZQS-3.8B-T1-EJ1, DC, 48V/3.8KW
BatteryTrojan 6×8V/170AH or US 6x8V/170AH
ControllerCurtis 1268-5403, 48V/400A
DashboardBattery Indicator
Wire harnessWaterproof wire harness IP67
Charger48V/25A, automatic power off, overload protection
FrameHigh strength aluminum alloy chassis
SuspensionFront suspension:Macpherson independent suspension ,Rear suspension:Single leaf spring and telescopic hydraulic shock absorbers
Real axleComplete rear axle, speed reducing ratio 16:1, Italian technology, Cast aluminum alloy gearbox housing
SteeringBidirectional output gear rack steering machine
BrakesMechanical drum brake &Electromagnetic excitation brake & Eletrical Parking
TireCarlisle 18×8.5-8(4ply), ≤22PSI
CanopyInjection, form in one piece, rain guide function
BodyModified PP injection cover, automobile grade color registers coating
WindshieldPC shield
SeatPU seat
Seat DirectionSame direction, one row,two seats
LightLED headlight; taillight; brake light
OthersRear view mirror, plastic basket, scoreboard kits, bunker rake position block and rear fender
Color□ White □ Red □ Green
Optional AccessoriesPart No. B420100□ Caddie stands
Part No. E030090□ Cooler box kit
Part No.  4063730□ Rain curtain
